WeAct 2.13" E-paper Display Black-White-Red
E-INK 2.13'' BWR
e-Ink display
SSD1680, SPI (4-pin)
250x122
Partial Refresh
- Model: WeAct 2.13" Epaper Module Black-White-Red
- Driver IC: SSD1680
- Interface Type: 4-pin SPI
- Resolution: 250 x 122 (130dpi)
- Screen Size: 23.7 x 48.55 mm (2.13 in)
- Physical Size: 29.2 x 59.2 x 0.95 mm
- Pixel Pitch: 0.194 x 0.194 mm
- Colors: black, white, red
- Datasheet
- Datasheet - SSD1680
- GitHub repository
- Reference C implementation
- Rust - weact-studio-epd
- Rust - ssd1680
